6. Using On-Screen Menu
➋
Menu Elements
Slide bar
Solid triangle
Highlight
Tab
Radio button
High Altitude symbol
Menu windows or dialog boxes typically have the following elements:
Highlight �����������������������������Indicates the selected menu or item�
Solid triangle ����������������������Indicatesfurtherchoicesareavailable.Ahighlightedtriangleindicatestheitemisactive.
Tab �������������������������������������� Indicates a group of features in a dialog box� Selecting on any tab brings its page to the front�
Radio button ����������������������Use this round button to select an option in a dialog box�
Source ��������������������������������Indicates the currently selected source�
OffTimerremainingtime ���Indicatestheremainingcountdowntimewhenthe[OFFTIMER]ispreset.
Slide bar �����������������������������Indicates settings or the direction of adjustment�
KeyLocksymbol ����������������Indicatesthe[CONTROLPANELLOCK]isenabled.
Thermometer symbol ���������Indicatesthe[ECOMODE]isforciblysetto[ON]modebecausetheinternaltemperatureistoo
high�
HighAltitudesymbol ���������Indicatesthe[FANMODE]issetto[HIGHALTITUDE]mode.
Source
Available buttons
Thermometer symbol
Key Lock symbol
Off Timer remaining
time
