6. Using On-Screen Menu
Selecting Aspect Ratio [ASPECT RATIO]
Theterm“aspectratio”referstotheratioofwidthtoheightofaprojectedimage.
Theprojectorautomaticallydeterminestheincomingsignalanddisplaysitinitsappropriateaspectratio.
•Thistableshowstypicalresolutionsandaspectratiosthatmostcomputerssupport.
Resolution AspectRatio
VGA  640x480  4:3
SVGA
 800x600  4:3
XGA
 1024x768  4:3
WXGA
 1280x768  15:9
WXGA
 1280x800  16:10
WXGA+
 1440x900  16:10
SXGA
 1280x1024  5:4
SXGA+
 1400x1050  4:3
UXGA
 1600x1200  4:3
Options Function
AUTO
Theprojectorwillautomaticallydeterminetheincomingsignalanddisplayitinits
aspectratio.
Theprojectormayerroneouslydeterminetheaspectratiodependingonitssignal.If
thisoccurs,selecttheappropriateaspectratiofromthefollowing.
4:3 Theimageisdisplayedin4:3aspectratio.
16:9 Theimageisdisplayedin16:9aspectratio.
15:9 Theimageisdisplayedin15:9aspectratio.
16:10 Theimageisdisplayedin16:10aspectratio.
WIDEZOOM Theimageisstretchedleftandright.
Partsofthedisplayedimagearecroppedattheleftandrightedgesandthereforenot
visible.
NATIVE
Theprojectordisplaysthecurrentimageinitstrueresolutionwhentheincomingcom-
putersignalhasalowerresolutionthantheprojector’snativeresolution.
[Example]Whentheincoming
signalwiththeresolutionof800x
600isdisplayed:
NOTE:
• Whenanon-computersignalisdisplayed,the[NATIVE]isnotavailable.
• Whenasignalwithahigherresolutionthantheprojector’snativeresolutionisdisplayed,[NA-
TIVE]isnotavailable.
Sample image when the appropriate aspect ratio is automatically determined
[Computersignal]
Aspectratioofincomingsignal 4:3 5:4 16:9 15:9 16:10
Sampleimagewhentheappro-
priateaspectratioisautomati-
callydetermined
