87
5. Installation and Connections
Designandmanufacturingconditionsforthestand
Pleaseengageaninstallationserviceproviderforthedesignandmanufactureofthecustomizedstandtobeusedfor
portraitprojection.Pleaseensurethatthefollowingarecompliedwithwhendesigningthestand.
1. Maintainadistanceofatleast100mmbetweentheprojectorintakeventandtheoor.
 Donotobstructtheintakeventatthefrontoftheprojector.
2. Usethefourscrewholesonthebottomfaceoftheprojectortosecureittothestand.
 Screwholecenterdimension:200×250mm
 Screwholedimensionontheprojector:M4withamaximumdepthof8mm.
* Pleasedesignthestandsuchthattherearlegsonthebottomfaceoftheprojectordonotcontactthestand.
Thefrontlegscanbeturnedandremoved.
3. Horizontaladjustmentmechanism(forexample,boltsandnutsinfourlocations)
4. Pleasedesignthestandsuchthatitdoesnottoppleovereasily.
Referencedrawings
* Thedrawingshowingthedimensionalrequirementsisnotanactualstanddesigndrawing.
[Side View] [Front View]
Screw holes for 4 - M4 use
Notch
160 × 35 or greater
200
Horizontal adjuster
(Unit: mm)
250
Intake vent
