2. Projecting an Image (Basic Operation)
❺ Adjusting the Picture Size and Position
Usethelensshiftdial,theadjustabletiltfootlever,thezoomlever/zoomringandthefocusringtoadjustthepicture
sizeandposition.
Inthischapterdrawingsandcablesareomittedforclarity.
Adjustingtheprojectedimage’sverticalandhorizontal
position[Lensshift]
(→page17)
Adjustingthefocus[Focusring]
(→page19)
Finelyadjustingthesizeofanimage
[Zoomlever]
(→page19)
Adjustingtheprojectedimage’sheightandhorizontaltilt
[Tiltfoot]
(→page20)
Correctingthekeystonedistortion[Keystone]*
(→page21)
* Toperformkeystonecorrectionmanually,see“6.CorrectingKeystoneDistortion[KEYSTONE]”onpage21.
