NEC P502WL - Removing the Cable Cover

123
9. Appendix
Removing the cable cover
1. Loosen the cable cover screws until the Phillips screw-
driver goes into a freewheeling condition.
• Whensuspended fromthe ceiling,hold sothat thecable
cover does not drop.
• Thescrewscannotberemoved.
2. Remove the cable cover.
(1) Rotate a little downwards so that the claw comes out of the
projector’s groove.
(2) Slide downwards so that the claw on the cover edge comes
out of the projector’s groove.
2
1
2
