5. Installation and Connections
Connecting to a Wired LAN
TheprojectorcomesstandardwiththeEthernet/HDBaseTport(RJ-45)andtheLANportwhichprovideaLANcon-
nectionusingaLANcable.
TouseaLANconnection,youarerequiredtosetthewiredLANsettingsontheprojectormenu.Select[SETUP]→
[INSTALLATION]→[NETWORKSETTINGS].(→page57).
ThenetworksettingscanalsobeselectedfromtheAPPSmenu.
ExampleofLANconnection
ExampleofwiredLANconnection
Ethernet
HDBaseT
Server
Hub
LAN cable (not supplied)
NOTE:Usea Category 5 or higher
LANcable.
NOTE:
• Abouttheprojector’sEthernet/HDBaseTandLANports
 TheEthernet/HDBaseTandLANportsarethesame,asidefromtheHDBaseTfunction.ToconnecttotheLAN,useonly1ofthe
ports(itisnotpossibletoconnectbothportstotheLAN).
 ForcontrollingtheprojectorbyaHDBaseTtransmitterwhosecontrolsignalisnotsupported(orwithwhichcannotconnectthe
projector)oroverthenetwork,connecttotheLANport.Atthesametime,forcontrollingtheprojectoroverthenetworkthatis
inthestateoftheNETWORKSTANDBYOn,connecttotheLANport.
