82
5. Installation and Connections
3. Insert the wireless LAN unit into the USB (wireless LAN) port
with the side containing the indicator facing up.
• SlowlyslidethewirelessLANunitleftandright,upanddown,
checkingtheinsertionslotasyoupushtheunitin.
NOTE:DonotforcetoinserttheUSBWirelessLANUnit.
4. Mount the wireless LAN cover.
(1)Insertthehookonthebackofthecoverintothegrooveinthe
projector and close the wireless LAN cover.
Groove
Hook
(2)Turnthescrewclockwisetotightenit.
* To remove the USB Wireless LAN Unit, disconnect the power
cord and use the above procedure.
NOTE:
• DonotpressthebuttonontheUSBWirelessLANUnit.Thebuttondoes
notworkwiththismodel.
