5. Using On-Screen Menu

EnteringthecurrentlyprojectedsignalintotheEntryList[STORE]

1. Press the ▲ or ▼ button to select any number.

2. Press the ◀ or ▶buttontoselect[STORE]andpresstheENTERbutton.

CallingupasignalfromtheEntryList[LOAD]

Pressthe▲or▼buttontoselectasignalandpresstheENTERbutton.

EditingasignalfromtheEntryList[EDIT]

1. Press the ▲ or ▼ button to select a signal you wish to edit.

2. Press the ◀, ▶, ▲, or ▼buttontoselect[EDIT]andpresstheENTERbutton.

 TheEditwindowwillbedisplayed.

SOURCENAME Enterasignalname.Upto18alphanumericcharacterscanbeused.

INPUT Theinputterminalcanbechanged.TheinputterminalmaybeswitchedtoHDMI1/HDMI2/Dis-

playPort/BNC/BNC(CV)/BNC(Y/C)/COMPUTER/HDBaseT([ETHERNET]forMMmodels).

LOCK Set so that the selectedsignalcannot be deleted when [ALL DELETE] is executed.The

changesmadeafterLOCKexecutioncannotbesaved.

SKIP Setsothattheselectedsignalwillbeskippedduringautosearch.

3. Settheaboveitemsandselect[OK]andpresstheENTERbutton.

NOTE: The input terminal cannot be changed to the currently projected signal.
