6. Installation and Connections
Connecting Component Input
• Selectthesourcenameforitsappropriateinputconnectorafterturningontheprojector.
Inputconnector
INPUTbuttonontheprojector
cabinet
Buttonontheremotecontrol
COMPUTERIN 7:COMPUTER 7/COMPUTER
BNCIN 4:BNC 4/BNC
NOTE:
• Whenthesignalformatissetto[AUTO](defaultfactorysettingwhenshipped),thecomputersignalandcomponentsignalare
automaticallydistinguished and switched. Ifthe signals cannot be distinguished, select [COMPONENT] under [ADJUST]→
[VIDEO]→[SIGNALTYPE]intheon-screenmenuoftheprojector.
• ToconnecttoavideodevicewithaDconnector,usethesoldseparatelyDconnectorconverteradapter(modelADP-DT1E).
AUDIO IN
COMPUTER IN
AUDIO IN
15-pin-to-RCA(female)×3
cableadapter(ADP-CV1E)
BNC(male)-to-RCA(male)conversioncable×3
(soldcommercially)
Stereominiplug-to-RCAaudiocable(not
supplied)
ComponentvideoRCA×3cable(not
supplied)
Blu-rayplayer AudioEquipment
