2. Projecting an Image (Basic Operation)

Applicable lens: NP30ZL

TheNP30ZLlensunitalignstheperipheralfocusaroundtheopticalaxis.

Peripheralfocusring

FocusRing

ZoomLever

1. Turn the focus ring left and right to align the focus

around the optical axis.

* Thediagramshowsanexamplewhenthelensshiftis

movedtothetop.Thetopofthescreenisadjusted.

 Whenthelensisinthecenter,thecenterofthescreen

isadjusted.

FocusRing

Opticalaxis

2. Turn the peripheral focus ring to the left and right to

align the focus of the overall screen.

 Atthispoint,thefocusaroundtheopticalaxisadjustedin

(1)remainsunchanged.

Peripheralfocus

ring
