5. Using On-Screen Menu

[MULTI SCREEN]

WHITEBALANCE

Thisadjuststhewhitebalanceforeachprojectorwhenprojectingusingacombinationofseveralprojectors.

Thiscanbeadjustedwhen[MODE]issetto[ON].

BRIGHTNESS W, BRIGHTNESS R, BRIGHTNESS G, BRIGHTNESS B

�� Adjusting the black color of the video�

CONTRAST W, CONTRAST R, CONTRAST G, CONTRAST B

�� Adjusting the white color of the video�

PICTURESETTING

Thissetsthedivisionconditionwhenprojectingusingacombinationofseveralprojectors.

Pleasereferto“4.Multi-ScreenProjection”(→page48)fordetails.

MODE OFF Usetheprojectorinastandalonestate.

ZOOM Thisadjuststhepositionandwidthofthevideoareathatyouwishtodivide.Theedge

blendingwidthwillalsobeautomaticallysettothatwidth.

TILING Thisassignsthedividedscreenstotheprojectors.Theedgeblendingfunctionwillalso

besetautomatically.

ZOOM HORIZONTAL

ZOOM

Thismaginiesthevideoareainthehorizontaldirection.

VERTICAL

ZOOM

Thismaginiesthevideoareaintheverticaldirection.

HORIZONTAL

POSITION

Thisshiftsthevideoareainthehorizontaldirection.

VERTICALPO-

SITION

Thisshiftsthevideoareaintheverticaldirection.

TILING WIDTH Thisselectsthenumberofprojectorstobearrangedhorizontally.

HEIGHT Thisselectsthenumberofprojectorstobearrangedvertically.

HORIZONTAL

POSITION

Thisselectsthepositionoftheprojectorstartingfromtheleftamongthosearranged

horizontally.

VERTICALPO-

SITION

Thisselectsthepositionoftheprojectorstartingfromthetopamongthosearranged

vertically.
