6. Installation and Connections

Connecting Component Input

• Selectthesourcenameforitsappropriateinputterminalafterturningontheprojector.

Inputterminal

SOURCEbuttonontheprojector

cabinet

Buttonontheremotecontrol

COMPUTER1IN COMPUTER COMPUTER1

BNC BNC COMPUTER2

NOTE:

• Whenthesignalformatissetto[AUTO](defaultfactorysettingwhenshipped),thecomputersignalandcomponentsignalare

automaticallydistinguished and switched. If the signals cannot be distinguished, select [COMPONENT] under [ADJUST] →

[VIDEO]→[SIGNALTYPE]intheon-screenmenuoftheprojector.

• ToconnecttoavideodevicewithaDterminal,usethesoldseparatelyDterminalconverteradapter(modelADP-DT1E).

COMPUTER 1 IN

15-pin-to-RCA(female)×3cableadapter

(ADP-CV1E)

BNC(male)-to-RCA(male)conversion

cable×3(soldcommercially)

ComponentvideoRCA×3cable(notsup-

plied)

Blu-rayplayer

AudioEquipment
