9. Appendix

❺ Cabinet Dimensions

Unit:mm(inch)

484.4 (19.1)

150 (5.9)

509 (20)

195 (7.7)

217 (8.5)

101 (4)

89 (3.5)

94.5

(3.7)

150 (5.9) 150 (5.9)

574.8 (22.6)

300 (11.8)

Lenscenter

6-M4×L8(Max)forCeilingMount*

* ThescrewsspecicationsforCeilingMount:

 Screwtype:M4

 Maximumscrewlength:8mm(0.31")

 Minimumscrewlength:6mm(0.24")

CAUTION:

Donotattempttomounttheprojectoronaceilingyourself.

Theprojectormustbeinstalledbyqualiedtechniciansinordertoensureproperoperationandreducetheriskof

bodilyinjury.

Inaddition,theceilingmustbestrongenoughtosupporttheprojectorandtheinstallationmustbeinaccordance

withanylocalbuildingcodes.Pleaseconsultyourdealerformoreinformation.
