NEC PX602UL - Appendix; Throw distance and screen size

153
9. Appendix
❶ Throw distance and screen size
Thisprojectorcanbeusedwith3kindsofoptionallenses(soldseparately).Thechartbelowshowscompatiblelenses
accordingtotheprojectormodel.Refertotheinformationonthispageandusealenssuitedfortheinstallationenvi-
ronment(screensizeandthrowdistance).Forinstructionsonmountingthelens,seepage121.
Lens(model)
Projector(modelname) NP34ZL NP35ZL NP36ZL NP37ZL
PX602UL-WH/PX602UL-BK Ye s Ye s No Ye s
PX602WL-WH/PX602WL-BK Ye s Ye s Ye s Ye s
Yes=canbeused,No=cannotbeused
Lens types and throw distance
PX602UL-WH/PX602UL-BK
Screensize Lensmodelname
NP34ZL NP35ZL NP37ZL
inch m inch m inch m
50"
40-51 1.0-1.3 51-64 1.3-1.7 63-123 1.6-3.2
60" 48-62 1.2 - 1.6 62-77 1.6 - 2.0 76-148 2.0-3.8
80" 64-83 1.7-2.1 83-104 2.1-2.7 103-198 2.6-5.1
100" 81-104 2.1 - 2.6 104-130 2.7-3.3 129-248 3.3-6.3
120" 97-125 2.5-3.2 124-156 3.2-4.0 155-298 4.0-7.6
150" 122-157 3.1-4.0 156-195 4.0-5.0 194-373 4.9-9.5
200" 163-209 4.1-5.3 208-261 5.3-6.6 260-498 6.6-12.7
240" 195-251 5.0-6.4 250-313 6.4-8.0 312-598 7.9-15.2
300" 244-314 6.2-7.9 313-392 7.9-10.0 391-748 9.9-19.0
TIP
Calculationofthethrowdistancefromthescreensize
NP34ZLlensthrowdistance(inch/m)=H×0.96toH×1.23:40"/1.0m(min.)to314"/7.9m(max.)
NP35ZLlensthrowdistance(inch/m)=H×1.23toH×1.54:51"/1.3m(min.)to392"/10.0m(max.)
NP37ZLlensthrowdistance(inch/m)=H×1.53toH×2.94:63"/1.6m(min.)to748"/19.0m(max.)
“H”(Horizontal)referstothescreenwidth.
*Figuresdifferbyseveral%withthetableabovebecausethecalculationisapproximate.
Ex.:Throwdistancewhenprojectingona150"screenwiththePX602UL-WH/PX602UL-BKusingtheNP35ZLlens:
Accordingtothe“ScreenSize(forreference)”table(→ page 155),H(screenwidth)=127.2"/323.1cm.
Thethrowdistanceis127.2"/323.1cm×1.23to127.2"/323.1cm×1.54=156.5"/397.4cmto195.9"/497.6cm(becauseofthe
zoomlens).
