9. Appendix
Lens shifting range
ThisprojectorisequippedwithalensshiftfunctionforadjustingthepositionoftheprojectedimagebyusingtheLENS
SHIFTbuttons(→page19).Thelenscanbeshiftedwithintherangeshownbelow.
NOTE:
• Pleasedonotusethelensshiftfunctionwhenprojectingportraitimages.Pleaseuseitwiththelensinthecenter.
Legend:V“Vertical”referstothescreenheightandH“Horizontal”referstothescreenwidth.Thelensshiftrangeis
expressedasaratioofheightandwidth,respectively.
100%V
50%V
50%V
20%V* 20%V*
20%V*
20%V*
100%H
15%H
15%H
15%H
15%H
10%H
10%H 10%H
10%H
Heightofprojectedimage
Widthofprojectedimage
ValueofX
PX602UL-WH/PX602UL-BK 20%V
PX602WL-WH/PX602WL-BK 30%V
* Thelensshiftrangeisthesameforceilinginstallation.
(Example)Whenusingtoprojectona150"screen
Accordingtothe“Tableofscreensizesanddimensions”(→page155),H=127.2"/323.1cm,V=79.5"/201.9cm.
Adjustment range in the vertical direction: the projected image can be moved upwards 0.5 × 79.5"/201.9 cm ≈
39.8"/101cm,downwardsapproximately39.8"/101cm(whenthelensisatthecenterposition).Adjustmentrangein
thehorizontaldirection:theprojectedimagecanbemovedtotheleft0.15×127.2"/323.1cm≈19.1"/48cm,tothe
rightapproximately19.1"/48cm.
* Figuresdifferbyseveral%becausethecalculationisapproximate.
