NEC PX602UL User Manual

139
6. Installation and Connections
AttachingStackingHolders
Attachthreestackingholderstothreelocationsonthetopofthelowerprojector.
Preparation:
ToolsrequiredarePhillipsscrewdriver(plus-head)andthreestackingholderspackagedwiththeprojector.
Loosenthetiltfeet(threelocations)oftheprojector.
1. Remove rubber caps and screws at three locations.
(1)Useyourtweezersornailtopinchandpulluptherubbercap.
(2)Removethescrewfromasquarehole.
(1) (2)
2. Attach the three stacking holders at three locations.
(1)Placeastackingholderinasquarehole.
(2)UsethescrewremovedatStep1toxthestackingholderinthesquarehole.
(3)PuttherubbercapremovedatStep1backintothesquarehole.
 • Snapthetabsonbothoftherubbercapintotheslitsonbothsidesinthesquarehole.
(1) (2) (3)
