Important Information

Clearance for Installing the Projector

Allowampleclearancebetweentheprojectoranditssurroundingsasshownbelow.

Thehightemperatureexhaustcomingoutofthedevicemaybesuckedintothedeviceagain.

AvoidinstallingtheprojectorinaplacewhereairmovementfromtheHVACisdirectedattheprojector.

HeatedairfromtheHVACcanbetakeninbytheprojector'sintakevent.Ifthishappens,thetemperatureinsidethe

projectorwillrisetoohighcausingtheover-temperatureprotectortoautomaticallyturnofftheprojectorspower.

Example 1 – If there are walls on both sides of the projector.

30cm/11.8"orgreater 30cm/11.8"orgreater

IntakeventExhaustvent

NOTE:

The drawing shows the proper clearance required for the front, back and top of the projector.

Example 2 – In the case of portrait projection.

Intakevent

Safetycover

30cm/11.8"orgreater

NOTE:

• Thedrawingshowstheproperclearancerequiredforthefront,backandtopoftheprojector.

• Seepage135 for an installation example on portrait projection.
