NEC PX602WL - Connecting Your Blu-Ray Player or Other AV Equipment

130
6. Installation and Connections
Connecting Your Blu-ray Player or Other AV Equipment
Componentvideosignal/S-videosignalconnection
• Selectthesourcenameforitsappropriateinputterminalafterturningontheprojector.
Inputterminal
SOURCEbuttonontheprojector
cabinet
Buttonontheremotecontrol
BNC(CV) BNC(CV) VIDEO
BNC(Y/C)
BNC(Y/C) S-VIDEO
CV YC
BNC（CV）
BNC（Y）
BNC（C）
BNCcable(notsupplied)
Audioequipment
