NEC PX602WL - Things to Note When Installing Projectors

4. Multi-Screen Projection
51
Things to note when installing projectors
• Leave1moroverspacebetweentheprojectorswhenprojectorsareinstalledsidebyside,sothattheintakeand
exhaustventsoftheprojectorsarenotobstructed.Inaddition,leaveaspaceofatleast30cmbetweentheintake/
exhaustventand thewall.Whenthe airintakeand dischargeoutletareobstructed,thetemperatureinsidethe
projectorwillriseandthismayresultinamalfunction.
1morgreater
• Twoprojectorscanbestackedontopofeachother(STACKsetting).(→page138)Donotattempttodirectlystack
threeormoreprojectors.Whentheprojectorsarepiledupontopofoneanother,theymayfalldown,resultingin
damageandfailure.
• Installationexamplewhenusing3ormoreprojectors
 Thefollowinginstallationisrecommendedwheninstallingacombinationof3ormoreprojectorsformulti-screen
projection.
[Installationexample]
IntakeventExhaustvent Cabinet
Airdischarge
Airintake
Front Front
WARNING
Pleaserequestthedealerforspecialinstallationservicessuchaswhenmountingtheprojectortotheceiling.Never
carryouttheinstallationbyyourself.Theprojectormayfalldownandresultininjury.Pleaseuseasturdycabinet
thatcanwithstandtheweightoftheprojectorfortheinstallation.Pleasedonotpileuptheprojectorsdirectlyon
topofoneanother.
NOTE:
• Fortherangeoftheprojectiondistance,pleaserefertotheAppendix“Throwdistanceandscreensize”.(→ page 153)
