NEC PX602WL - Adjusting the Tilt Foot

22
2. Projecting an Image (Basic Operation)
Adjusting the Tilt Foot
1. Theposition to project image may be adjusted bythe tilt feet
positionedatright,leftandrearofthecabinetbottom.
 Thetiltfootheightcanbeadjustedbyitsturn.
 “Toadjusttheheightoftheprojectedimage”
 Theheightoftheprojectedimageisadjustedbyturningtheleftand
righttiltfeet.
 “Iftheprojectedimageistilted”
 Iftheprojectedimageistilted,turnoneofthetiltfeettoadjustthe
imagesothatitislevel.
 “Toadjusttheprojectorsothatitisperpendiculartothescreen”
 Turnthereartiltfoottoadjustitsheight.
• Iftheprojectedimageisdistorted,see“3-7CorrectingHorizontal
andVerticalKeystoneDistortion[CORNERSTONE]”(→page32)
and“[GEOMETRICCORRECTION]”(→page100).
• Thetiltfootcanbelengthenedbyamaximumof48mm.
• Thetiltfootcanbeusedtotilttheprojectorbyamaximumof6°.
NOTE:
• Donotlengthenthetiltfootanymorethan50mm/1.9".Doingsowillmakethe
tilt feet’s mount section unstable and could cause the tilt feet to come off the
projector.
• Donotusethetiltfootforanypurposeotherthanadjustingtheprojector’s
projection angle.
 Handlingthetiltfootimproperly,suchascarryingtheprojectorbygraspingthe
tilt foot or hooking it onto a wall using the tilt foot, could damage the projector.
Up
Tiltfoot
(thereisonemoreintherear)
Down
