1. Introduction
❹ Part Names of the Remote Control
1. Infrared Transmitter
(→page11)
2. RemoteJack
 Connectacommerciallyavailable
remotecablehereforwiredopera-
tion.(→page11)
3. POWERONButton
(→page14)
4. POWEROFFButton
(→page24)
5. INFO/L-CALIB.Button
 Displaythe[SOURCE(1)]screen
oftheon-screenmenu.
(→page117)
6. VOL./FOCUS+/−Buttons
(→page21)
7. D-ZOOM/ZOOM+/−Buttons
(→page28)
8. TESTButton
(→page70)
9. ECO/L-SHIFTButton
(→page20,29)
10.MENUButton
(→page62)
11.EXITButton
(→page62)
12.ENTERButton
(→page62)
13. ▲▼◀▶Button
(→page62)
14.ON-SCREENButton
(→page26)
15.SHUTTERButton
(→page26)
16.AV-MUTEButton
(→page26)
17.PICTUREButton
(→page74,76)
18.SOURCEButton
(→page16)
19.3DREFORMButton
(→page32)
20.PIP/FREEZEButton
(→page27,53)
1
3
4
6
14
10
12
16
20
7
2
5
8
9
11
15
18
17
13
21
19
25
28
32
23
22
35
24
30
26
29
34
27
31
36
33
21.AUTOADJ.Button
(→page23)
22,23,24.COMPUTER1/2/3But-
ton
(→
page16)
25.VIDEOButton
(→page16)
26.S-VIDEOButton
(→page16)
27.HDMIButton
(→page16)
28.DisplayPortButton
(→page16)
29.VIEWERButton
 (TheVIEWERbuttonwillnotwork
onthisseriesofprojectors.)
30.NETWORKButton
(→page16)
31.SLOTButton
(→page158)
32.IDSETButton
(→page105)
33.Numeric(0to9/CLEAR)But-
tons
(→
page105)
 (TheAUXbuttonwillnotworkon
thisseriesofprojectors.)
34.CTLButton
 Thisbuttonisusedinconjunction
with other buttons, similar to a
CTRLkeyonacomputer.
35.LIGHTButton
 Thisbuttonisusedtoturnonthe
backlight for the remote control
buttons.
 Thebacklight will turn off if no
buttonoperation is made for10
seconds.
36.HELPButton
(→page117)
