20
2. Projecting an Image (Basic Operation)
Adjusting with the remote control
1. HoldtheCTLbuttonandpresstheECO/L-SHIFTbutton.
 The[LENSSHIFT]screenwillbedisplayed.
2. Press the ▼▲◀ or ▶ button.
 Usethe▼▲◀▶buttonstomovetheprojectedimage.
TIP:
• ThediagrambelowshowsthelensshiftadjustmentrangeforthePX602UL-WHandPX602UL-BK(projectionmode:desktop
front).Toraisetheprojectionpositionhigherthanthis,usethetiltfeet.(→ page 22)
• ForthePX602WL-WH/PX602WL-BKandtheceilingmount/frontprojectionlensshiftadjustmentrange,seepage156.
100%V
50%V
50%V
20%V* 20%V*
20%V*
20%V*
100%H
15%H
15%H
15%H
15%H
10%H
10%H 10%H
10%H
Heightofprojectedimage
Widthofprojectedimage
* 30%VforthePX602WL-WH/PX602WL-BK.
 Descriptionofsymbols:Vindicatesvertical(heightoftheprojectedimage),Hindicateshorizontal(widthoftheprojectedimage).
