2. Projecting an Image (Basic Operation)
Adjusting the vertical position of a projected image (Lens shift)
CAUTION
• Performtheadjustmentfrombehindorfromthesideoftheprojector.Performingadjustmentfromthefrontcould
exposeyoureyestostronglightwhichcouldinjurethem.
• Keephandsawayfromthelenshoodwhilethelensshiftisinoperation.Failuretodosocouldresultinngers
beingpinchedbetweenthelensandthelenshood.
Adjusting with buttons on the cabinet
1. Press the LENS SHIFT/HOME POSITION button.
 The[LENSSHIFT]screenwillbedisplayed.
2. Press the ▼▲◀ or ▶ button.
 Usethe▼▲◀▶buttonstomovetheprojectedimage.
• Returningthelensshiftpositiontothehomeposition
 PressandholdtheLENSSHIFT/HOMEPOSITIONbuttonfor2secondstoreturnthelensshiftpositiontothe
homeposition(nearlycenterposition)
