© by N&W GLOBAL VENDING S.p.A. 23 10 2009 3325 - 00
KEYBOARD
According to models, the external keyboard may be by
way of direct selection or, as an alternative, with numeric
keys.
If the machine is set to the Filler or Technician mode, the
keys of the selection pushbutton panel will assume the
functions shown by the gure and the corresponding
leds will turn on:
scrolling keys
and
:
used to move to the previous menu option or to the next
one and to modify the values (plus and less).
enTer key :
used to move from a menu to a sub-menu or to conrm
the data item on the display.
exiT key :
used to go back from a sub-menu to a higher level menu or
not to conrm the data item that is currently active.
It is also used to move from the “Technician” mode to the
“Filler” mode and vice versa.
To access the programming menus, power on the ma-
chine when the door is open by acting on the door switch
and by pressing the programming button.
POWER ON
Whenever you power on the machine, the display will
show the software release number.
CANTO
software rev. x.x
machine board rev. x.x
TOTAL VENDS: xxxxxx
If the grinder is complete with an automatic regulation
device and an operation failure is found out, the following
messages can be displayed as soon as you power on
the machine:
Wear grinding wheels 1
if the average grinding time should exceed the average
time of the rst grinding cycles by 50% or:
Check grinding wheels 1
if 40 selections have been performed, but the machine
has not become stable yet. The automatic regulation is
no longer performed.
If no failure is found out or the grinder is manually regu-
lated, no message is displayed.
You can programme the machine to display the number
of dispensing cycles you have performed for some sec-
onds.
A check is performed on espresso boilers.
Heating
After having completed the power-on cycle, the display
will show the following message after some seconds:
Running
SELECT A DRINK
Fig. 28
