© by N&W GLOBAL VENDING S.p.A. 24 10 2009 3325 - 00
NORMAL OPERATION MODE
The message requiring the user to select a drink will ap-
pear on the display during the normal operation.
The key function may vary according to the layout and
the choices you have made during programming.
SELECT A DRINK
If you insert some coins into a payment system, the
credit still available will appear on the display.
SELECTION no. XXX
x
Price 0.30
Whenever you request for a selection, if the credit is not
enough, the display will show the selection price, the
credit available and the residual amount you have to
insert in sequence.
A status bar is displayed during the dispensing cycle. It
will show the drink preparation level.
WAIT PLEASE
If the control system should nd out a failure, an error
message will appear and specify the type of problem:
VENDING MACHINE
OUT OF ORDER
“Failure name”
At the end of the dispensing cycle, the request to take
the drink will appear on the display for some seconds
and the machine will get ready for another delivery.
DRINK READY
SERVE YOURSELF
FILLER MENU
Press the programming button on the machine door
once to set the machine to the “ller menu” mode.
The rst item of the “ller” menu appears on the display
with a series of available operations.
The last line shows the menu and number showing the
level you are in.
Press the Enter key
to access the menu.
Press the Exit key
to go back to the previous menu..
Press the keys
and
to scroll the menu items:
FILLER
STATISTICS
INDIVIDUAL PRICE
TUBE MANAGEMENT
BOILER TEMPERATURES
TEST
GSM
EVADTS
FILLER> X.X
STATISTICS
All the data relative to the machine operation are stored
in total and relative counters that can be reset without
losing total data.
STATISTICS
PRINT STATISTICS
PRINT RELATIVE STATISTICS
DISPLAY STATISTICS
DISPLAY RELATIVE STATISTICS
DELETE RELATIVE STATISTICS
FILLER> X.X
prinT
This function is intended to print the data that have been
stored for the machine operation.
Connect an RS232 serial printer having 9600 baud rate,
8 data bits, no parity, 1 stop bit with the serial port on the
button board in order to print all statistics, i.e:
ToTal
1 - counter by selection;
2 - counter for bands,
3 - discount counter:
4 - failure counter;
5 - coin mechanism data.
relaTive
1 - counter by selection;
2 - counter for bands,
3 - discount counter:
4 - failure counter;
5 - coin mechanism data.
