4 Connections
The ANPR is delivered with two 5m long cables. Power supply, RS485 communication and I/O are combined in one cable.
Ethernet network is a second cable. The cables are pre-fitted to the ANPR. For installation the ANPR does not need to be
opened.
4.1 Ethernet connection
The Ethernet cable is already fitted to the ANPR provided an RJ-45 connector. This Cat5e cable will be adequate for
connection of the unit to a local area network. The ANPR LUMO can also be powered through Power Over Ethernet
(802.3af or 802.3at).
4.2 Power supply
RED Power supply +24VDC ~ 1A
BLUE Ground 0V
BLACK Ground 0V
Note: the ANPR LUMO may also be powered through PoE (802.3af) or PoE+ (802.3at)
4.3 RS485 connection
YELLOW RS-485 A
GREEN RS-485 B
PURPLE RS-485 GND
4.4 Wiegand connection
WHITE Wiegand Data-0
BROWN Wiegand Data-1
PURPLE Wiegand GND
4.5 Digital I/O
PINK Digital input IN 1 + (optocoupler positive contact, U = 5 - 24VDC)
GRAY Digital input IN 1 -
GRAY/PINK Digital input IN 2 + (optocoupler positive contact, U = 5 - 24VDC)
RED/BLUE Digital input IN 2 -
WHITE/GREEN Relay output 1 (normally open contact, U
max
= 24VDC, I
max
= 2A).
BROWN/GREEN Relay output 1 (common contact).
WHITE/YELLOW Relay output 2 (normally open contact, U
max
= 24VDC, I
max
= 2A).
BROWN/YELLOW Relay output 2 (common contact).
