ANPR LUMO | installation guide
9/45
3.2.2 Behind barrier mounting
The ANPR is positioned behind the barrier at bumper height.
If there is space behind the barrier and the sight is not blocked, then the best place for the ANPR is at bumper height
(0.5m height) about 2 to 3 meters behind the barrier. A vehicle just in front of the barrier is still recognized in that case.
Figure 2: Behind the barrier mounting (ANPR LUMO)
3.3 Dimensions
Figure 3: ANPR housing dimensions
76.5
104
104
M6 (4x)
76.5
M4x12 (6x)
35
91
118
10 m 2 m 1 m 0 m
