23. Baud Rate switches: Set the baud rate for serial
communications.
24. RS-232 Format switches: Set the RS-232 format.
25. Adult/Neonatal Alarm switch: Sets the default alarm
limits for adults or neonates.
26. RATE connector: Provides analog voltage output of pulse
rate in beats per minute, with a range of 0–250 bpm.
27. SERIAL COMM connector: Provides RS-232 digital
interface via a 9-pin “D” connector.
28. SAT connector: Provides analog output of oxygen
saturation data.
29. DATA connector: Provides a digital signal via fiber-optic
output.
30. PULSE connector: Provides analog output of pulse
waveform.
31. AC power inlet.
32. Fuse compartment.
33. Fuse label.
