CONNECTING TO OTHER INSTRUMENTS
Overview
RS-232 Communication Protocol
Connecting the N-7000 Interface
Connecting the N-7500 Network
Connecting the N-9000 Recorder/Interface
Connecting Other Strip-Chart Recorders
Connecting the ThinkJet Printer
Connecting the P-200 Printer
OVERVIEW
WARNING: When connecting this monitor to any
instrument, verify proper operation before clinical use.
Refer to the other deviceÕs manual for full instructions.
Accessory equipment connected to the monitorÕs analog
or digital outputs must be certified according to the
respective standards, that is, IEC 950 for data-
processing equipment or IEC 601.1 for electromedical
equipment and must comply with the requirements for
medical systems, IEC 601.1.1. If in doubt, contact
NellcorÕs Technical Services Department or your local
Nellcor representative.
This section contains information to allow the user to provide
serial communications between the N-200 and external digital
devices.
RS-232 COMMUNICATION PROTOCOL
Serial Data Connector Pin Assignments
Table 4 lists pin assignments on the rear-panel SERIAL
COMM connector and the corresponding pin assignments for a
25-pin RS-232 connector.
