Specifications
87
ECG
Direct ECG input
Via C-13-200 or C-20-200 patient module
Input
Defibrillator protected, differential; Lead II only
Bandwidth
0.5–40 Hz (monitoring bandwidth)
CMRR
Greater than 100 dB at 50 or 60 Hz with 5 kilohms source
imbalance
Input Range
±0.5-5.0 mV for QRS detection
Input Impedance
greater than 10 megohms
Via Rear-Panel ECG IN/OUT Connector
Input
Defibrillator sync or ECG output waveform from bedside ECG
monitor. Defibrillator protected, differential, standard Lead II
configuration. For optimum performance, waveform with
positive deflection recommended.
Input Range
±0.5 V minimum input signal; should not exceed ±15 V.
Minimum of 10 ms wide at 50% of peak amplitude, delayed by
no more than 40 ms from actual QRS complex.
