N1500i FACS Manual
26
Part No. 729-110-053 V.1.03 © 2018 Nelson Stud Welding, Inc. All rights reserved.
Drawn Arc Welding
*Assuming 3 phase input power and a short circuit on - time of
100ms
Stud Weld Rate
Parameters listed are those used during testing, and should be used only when considering operating duty cycle
Stud Size
Time
(sec)
Current
(A)
Weld Rate (Studs Per Minute)
(in)
mm
Nelweld 1500i
3/16”
5mm
0.15
300
261
1/4”
6mm
0.17
400
171
5/16”
8mm
0.25
450
105
3/8”
10mm
0.33
500
70
7/16”
11mm
0.42
625
38
1/2”
13mm
0.55
750
21
5/8”
16mm
0.67
1100
8
3/4”
19mm
0.84
1400
4
3.3.10 Stud Expert
TM
weld table
The following Stud Expert weld table is programmed into the welder
control system. It provides automatic weld settings, based on stud type
and diameter.
There are conditions that will filter the table for selection, or reveal only a
subset of the table to the user.
• In the case of the N1500i, studs requiring more than 1500A of
weld current will not appear in the list for selection.
• Input Power - If the maximum current on the N1500i is limited
to 800A due to single phase input power, studs requiring >800A
will not display in the list.
Stud
l
standard
t
standard
l
aluminum
t
aluminum
Process
3mm Pitch Base
200,
100,
100,
160
Drawn Arc
3mm Full Base
220,
100,
110,
170,
Drawn Arc
3mm IS-Bolzen
200,
150,
200,
150,
Drawn Arc
3mm SC-Bolzen M3
400,
15,
400,
15,
Short Cycle
3/16” Pulse
160,
200,
160,
200,
Drawn Arc
3/16" Pitch Base
280,
140,
150,
230,
Drawn Arc
3/16" Full Base
310,
150,
160,
250,
Drawn Arc
Note!
