8.3.17 Additional Warning - WAIT is on upper
display and CYCLE or CAP is on lower display
Description: ‘WAIT’ will display for the following 3 reasons:
6. Weld duty cycle is being exceeded
7. Switch board is out of calibration
8. Switch board malfunctioned
If lower display reads “CYCLE”,
Check Duty Cycle of the power unit.
If lower display reads “CAP”,
Step 1: Check Switch Board Calibration: Switch boards generate a
signal representing the capacitor voltage for the FACS input board.
Step 2: Switch Board Malfunction: If re-calibration of the switch board
fails, exchange the switch board.
