N1500i FACS Manual

10. Spare Parts List for N1500i

Part Number

Description

750-610-054

Switchboard A

750-610-055

Switchboard B

709-256-015

Main Power Switch

750-510-022

Input Board

750-610-062

Pilot Arc Board

750-649-065

Dot Matrix User Interface

750-649-035

SMPS Output Board

750-649-045

Input Sensing Board

750-649-040

Gun Interface Board

701-175-000

3 Phase Bridge Rectifier

750-610-034

Output Rectifier Board
