Nelson N800i - Performing a Lift Check

N1500i FACS Manual
28
Part No. 729-110-053 V.1.03 © 2018 Nelson Stud Welding, Inc. All rights reserved.
12mm Pitch Base
680,
380,
370,
690,
Drawn Arc
12mm Full Base
780,
440,
420,
820,
Drawn Arc
12mm MM12, S12
950,
450,
950,
450,
Drawn Arc
12mm SC-Bolzen M12
1300,
50,
1300,
50,
Short Cycle
1/2" Pitch Base
730,
410,
390,
750,
Drawn Arc
1/2" Full Base
840,
480,
450,
890,
Drawn Arc
1/2” Pulse
450,
850,
450,
850,
Drawn Arc
13mm Pitch Base
750,
420,
400,
770,
Drawn Arc
13mm Full Base
860,
500,
460,
920,
Drawn Arc
If the vertical position is selected, selection of some studs will provide a 10%
increase in current and 15% reduction of weld time from the values shown above.
3.3.11 Performing a Lift Check
The gun lift can be measured by holding the gun trigger for a few
seconds:
• Isolate the gun (so as not to start weld).
• Pull and hold down the trigger. The gun will lift and release for the
programmed weld time. (Continue holding the trigger for 2 more
seconds)
• The gun will lift for 2 seconds then release. During the 2 seconds,
a manual measurement may be taken.
Warning!
check.
