Nelson N800i - Operational Function Codes & Error Codes; Function Codes

N1500i FACS Manual
44
Part No. 729-110-053 V.1.03 © 2018 Nelson Stud Welding, Inc. All rights reserved.
4. Operational Function Codes & Error Codes
Dot Matrix Firmware version 1.00
4.1 Function Codes
F
code
Description
Possible Values
Default
Unit
Notes
F0
Language
ENGLISH,GERMAN,
ITALIAN,SPANISH,
FRENCH, POLISH
ENGLISH
x
F1
Error Display
E--- to E021
E---
x
F2
Plunge Short Circuit
On-Time
0 to 150
20
ms
When short cycle mode is enabled, this defaults to
20ms. When disabled, this defaults to 80ms for 2-wire
gun interface, 20ms for 4-wire gun interface.
F7
Output Board
Calibration Gain
95-105
%
Used by manufacturing. Do not change
F8
Chuck Saver
OFF ON
ON
x
F9
Gas Enable
OFF ON
OFF
x
F10
Gas Pre-flowTime
10 to 2000
500
ms
F11
Gas Post-flow Time
10 to 2000
500
ms
F12
Stud Feed Enable
OFF ON
OFF
x
This automatically turns on ‘short cycle mode’ when
enabled. Disabling it does not disable ‘short cycle mode’.
F13
Stud Feed Time
10 to 2000
50
ms
Pulse width of stud feed signal. This only applies when stud
feed is enabled.
F14
Stud Feed Normal Level
NORMAL CLOSED,
NORMAL OPEN
NORMAL OPEN
x
This only applies when stud feed is enabled.
F15
Stud Feed Style
AFTER CONTACT BREAK,
AFTER WELD
AFTER CONTACT
BREAK
x
When to get the signal. This only applies when stud feed is
enabled.
F16
Stud Feed on Air
Trigger
OFF ON
OFF
x
To feed a stud even when triggering the gun while not
welding. This only applies when stud feed is enabled.
