F code
Description
Possible Values
Default
Unit
Notes
F17
Load bank Enable
OFF
OFF
x
For manufacturing. This is a read-only function used for
burn-in testing.
F18
Capacitor V-F Readings
0-65535
NA
Hz
Time-up/down to see both sides
F19
Lock Mode
1 to 4
1
x
Mode 1: Use the lock key to toggle blocking on all keys -
no password protection. Mode 2: Use the lock key to enter
a password, lock key as 'enter'. From there, all keys are
blocked until you press lock again. It will prompt for the
same password entered when originally locked. Password
can be up to 9 characters. Mode 3: Same as mode 2,
except user can toggle between presets and cannot
change the value of presets. Mode 4: Same as mode 3,
except user can vary the time and current by the
percentage as set by F57.
F21
User Counter
0 to 4.3G
0
Welds
While in this F code, press and hold the time-down button
to reset the counter
F22
Total Counter
0 to 4.3G
0
Welds
(Non-resettable)
F24
Stud Expert Mode Unit
Selection
English, metric, or both
English
x
Allows the user to select which units are displayed as
stud sizes while in Stud Expert mode. This defaults to
English with 2-wire gun interfaces and Metric with 4-wire
gun interfaces.
F25
Software Versions
x
Time-up/down to see all versions
F26
Restore Factory Defaults
HOLD TIME DOWN
BUTTON
HOLD TIME DOWN
BUTTON
x
While in this F code, press and hold the time-down button
to reset all F codes to default.
F31
Drop Time
0 to 100
35
ms
This is a drop time measurement function THAT DOES
AN ACTUAL WELD. If F48 (Drop Time Configuration) is
in either Manual or Auto mode, the measurement taken
during the weld (while viewing this function) will be stored
in this function and used in weld timing. The measured
value may be overridden by using the arrow keys. This
value changes automatically depending on F30 (short
cycle mode) and the gun interface installed in the unit.
