1.Welding cable connection (-) X2
3. Control cable connection (X1)
2.Welding cable connection (+) X3
4. Input power cable connection
Warning!
Prior to any connection work the Nelweld N1500i welding unit must
be switched off. The input power switch of the unit must be in the
>>0<< position!
