Stud welding unit N800i
As of 24.08.2021
Manual part number: BE 1227
Tucker GmbH, Mail / Post: Max-Eyth-Str.1, 35394 Gießen, Germany
101
9.1.1 Parts List Final Assembly N800i
Item
QTY
Part Number
Comment
Description
1
1
750‐611‐404
CHASSIS SUBASSEMBLY
2
1
750‐611‐401
VERTICAL PANEL SUBASSEMBLY
3
1
750‐611‐405
COVER SUBASSEMBLY
4
1
750‐611‐403
FRONT PANEL SUBASSEMBLY
5
1
750‐611‐205
BRACKET, CONTROL BOARD MOUNTING
6
1
750‐610‐074
CONTROL BOARD ASSEMBLY
7
1
750‐611‐081
DISPLAY/USER INTERFACE PCB
8
2
708‐143‐003
FUSE HOLDER
9
2
715‐039‐001
FUSE, 1.5A, 600V
10
1
700‐142‐003
CURRENT TRANSFORMER (LEM)
11
1
750‐611‐225
INSULATOR PANEL, LEXAN
12
1
66‐08‐99
INPUT CABLE
13
1
724‐574‐007
RATINGS PLATE
14
1
723‐242‐031
GAS VALVE AND HARNESS ASSEMBLY
17
1
66‐09‐00
CE FILTER PCB ASSEMBLY
18
6
524‐005‐210
M4 KEPS NUT, SS (CONTROL PCB/COVER
GROUND/FRONT PANEL GROUND
MOUNTING)
19
5
524‐005‐273
M6 KEPS NUT, SS (VERTICAL PANEL/
CONTROL BD BRACKET/INPUT CABLE
GROUND MOUNTING)
20
2
524‐005‐278
M4x25 SHCS, SS (VALVE MOUNTING)
21
8
524‐005‐124
M5x12 PHCRMS, SS (CONNECTOR PANEL
MOUNTING)
22
8
524‐005‐256
M5 LOCK WASHER, SS (CONNECTOR
PANEL MOUNTING)
23
4
524‐005‐283
M4x6 PHMS, SS (USER INTERFACE
MOUNTING)
25
10
524‐005‐206
M6x16 HWHMS, SS (COVER MOUNTING
26
4
524‐005‐271
M3x12 PHCRMS, SS (FUSE HOLDER
MOUNTING)
27
4
524‐005‐279
M4x16 PHMS, SS (LEM/INSULATOR PANEL
MOUNTING)
28
2
524‐005‐010
M4 INTERNAL TOOTH WASHER (CHASSIS
GROUND/COVER GROUND MOUNTING)
29
1
524‐005‐285
M6 INTERNAL TOOTH WASHER (INPUT
CABLE GROUND MOUNTING)
30
1
724‐569‐013
LABEL, TRASH CAN, CE
31
4
724‐485‐010
LABEL, ELECTRICAL GROUND
32
1
724‐485‐013
LABEL, FUSE, ʺF1ʺ
33
1
724‐485‐014
LABEL, FUSE, ʺF2ʺ
34
1
87‐09‐35
LABEL, CARDIAC PACEMAKER
35
1
87‐05‐19
LABEL, POWER PLUG
