Stud welding unit N800i
As of 24.08.2021
Manual part number: BE 1227
Tucker GmbH, Mail / Post: Max-Eyth-Str.1, 35394 Gießen, Germany
105
9.3.1 Parts list chassis sub ASM
Item
QTY
Part Number
Comment
Description
1
1
750‐611‐221
CHASSIS WELDMENT
2
1
750‐611‐407
FAN SUB ASSEMBLY
3
4
729‐022‐008
Leveling feet
4
1
714‐074‐010
CABLE GLAND
5
1
714‐074‐011
CABLE GLAND NUT
6
4
524‐005‐279
M4x16 PHMS, SS (FAN MOUNTING)
7
4
524‐005‐284
M4 FENDER WASHER, SS (FAN
MOUNTING)
8
5
524‐005‐210
M4 KEPS NUT, SS (FAN/CHASSIS
GROUND MOUNTING)
9
4
717‐140‐010
GROMMET, RUBBER (FAN
MOUNTING)
10
1
524‐005‐273
M6 KEPS NUT (CHASSIS GROUND
MOUNTING)
11
1
524‐005‐010
M4 INTERNAL TOOTH WASHER
(CHASSIS GROUND MOUNTING)
12
1
524‐005‐285
M6 INTERNAL TOOTH WASHER
(CHASSIS GROUND MOUNTING)
13
1
723‐245‐040
HARNESS, CHASSIS GROUND
Comment:
Sp = Spare part; Stp = Standard part; W = Wearing part;
Ssp = Stud‐specific part; NS = Not shown
