9.4.1 Parts list Front panel assembly
Item
QTY
Part Number
Comment
Description
1
1
750‐611‐243
FRONT CONNECTOR PANEL
2
1
520‐001‐251
COUPLING,QUICK PLUG
3
1
520‐001‐252
COUPLING,QUICK SOCKET
4
2
520‐001‐320
FITTING,FEMALE,M6 TUBING x G1/8
6
2
85‐10‐02
DINSE,FEMALE (M10 SCREW)
7
1
723‐245‐041
HRNS TRIGGER CONNECTOR (4
WIRE BINDER)
8
1
714‐232‐003
COVER,CONNNECTOR,BINDER
9
2
524‐005‐271
SCREW,M3x12 PHCRMS,SS
(TRIGGER HARNESS MTG)
NS
1
723‐242‐015
HRNS OUTPUT BD TO WORK DINSE (+)
NS
1
723‐242‐039
HRNS OUTPUT FILTER CAPACITOR
ASM
Comment:
Sp = Spare part; Stp = Standard part; W = Wearing part;
Ssp = Stud‐specific part; NS = Not shown
