Stud welding unit N800i
As of 24.08.2021
Manual part number: BE 1227
105
9.5.1 Parts list Vertical panel assembly
Item
QTY
Part Number
Comment
Description
1
1
750‐611‐402
VERTICAL/TRANSFORMER ASSEMBLY
2
1
701‐175‐000
3 PHASE BRIDGE RECT.
3
2
729‐114‐201
M5x35 HEX SPACER, FEMALE/FEMALE
(BRIDGE MOUNTING)
4
1
750‐611‐022
INPUT PCB ASSEMBLY
5
1
750‐611‐031
OUTPUT PCB ASSEMBLY
6
1
750‐610‐042
Power supply PCB assembly
7
4
729‐114‐202
M4x40 HEX SPACER, MALE/FEMALE
(POWER BD MOUNTING)
8
4
524‐005‐279
M4x16 PHMS, SS (POWER
BOARD MOUNTING)
9
4
524‐005‐010
M4 LOCK WASHER, SS (POWER
BOARD MOUNTING)
10
4
524‐005‐120
M4 FLAT WASHER, SS (AUX
TRANSFORMER MOUNTING)
11
1
750‐611‐051
SWITCHING PCB ASSEMBLY
12
1
750‐610‐062
PILOT ARC PCB ASSEMBLY
13
1
723‐245‐007
AUXILIARY TRANSFORMER ASSEMBLY
14
4 in
727‐029‐212
EDGE GUARD
15
20
524‐005‐210
M4 KEPS NUT, SS (PCB, AUX
TRANSFORMER MOUNTING)
16
2
714‐028‐002
CABLE GROMMET, LARGE
17
2
714‐028‐001
CABLE GROMMET, SMALL
18
1
723‐242‐021
CURRENT TRANSFORMER SUB ASM
19
2
524‐001‐340
WASHER, RUBBER (CT MOUNTING)
NS
1
723‐242‐025
HARNESS, OUTPUT RECT TO CONTROL
NS
1
723‐245‐002
HARNESS, CONTROL TO INPUT, SWITCH,
CTs, & PILOT
NS
1
723‐245‐003
HARNESS, CONTROL TO DISPLAY
NS
4
717‐615‐101
TY‐WRAP (CT MOUNTING)
NS
1
723‐245‐009
HARNESS, 3 PHASE BRIDGE (+) TO
INPUT (DC IN)
NS
1
723‐245‐011
HARNESS, 3 PHASE BRIDGE (‐)
TO SWITCH (B IN(‐))
NS
1
723‐245‐037
HARNESS, INPUT (DC OUT) TO SW (A IN
(+))
NS
1
723‐245‐038
HARNESS, SWITCH (A IN (‐)) TO SWITCH
(B IN (+))
NS
1
723‐245‐001
HARNESS, POWER SUPPLY CONTROL
TO FAN
NS
12 in
727‐029‐214
SLEEVING, FIBERGLASS (MAIN XFMR,
PRIMARY LEADS)
Comment:
Sp = Spare part; Stp = Standard part; W = Wearing part; NS = Not shown
