Stud welding unit N800i
As of 24.08.2021
Manual part number: BE 1221
Tucker GmbH, Mail / Post: Max-Eyth-Str.1, 35394 Gießen, Germany
When enabled, the current will change to the selected value while the
stud is plunging.
When Plunge Current (F46) is enabled, this current will be used during
the plunge state. MAX_CURRENT will depend on the power unit model
(N1500i or N800i) and power input (3 phase or single phase)
In Manual mode, F31 (drop time func- tion) is the only way to configure
the drop time. In Auto mode, F31 automa- tically gets a new value taken
from the first weld done after power-up and af- ter the gun is unplugged.
In Average mode, the average of the last 10 welds’ drop times are used
and displayed in F31.
Enable this to use pulse welding, where the main current pulses to a
high and low current setting at variable time settings per F codes F50-
F52.
This is the current used as the lower of the two currents during the weld.
(The front panel current setting will be the high current). MAX
CURRENT is the maximum current the unit can deliver given the power
conditions and model
This is the time the weld will deliver the front panel current.
