Elements Needed to Determine Billed
Reading
Small Meters
⅝ inch - 1 inch
1 Cu. Ft. Dial
Intermediate
Meters
1½ inch - 4 inch
10 Cu. Ft. Dial
Large Meters
6 inch and up
100 Cu. Ft. Dial
Typical meter dials
Four-digit meter reading
1234 1234 1234
Actual cumulative meter reading 123,456 cu. ft. 1,234,560 cu. ft. 12,345,600 cu. ft.
Required billing units 1234 12345 123456
Billing system multiplier and billed meter
reading
1234 x 1 = 1234 1234 x 10 = 12340 1234 x 100 = 123400
Table 8 – Meter Reading Display - Four Digit Remotes
*Required billing units = 100 cu. ft. increments
ProRead™ (ARB
®
VI) Registers
The Neptune ProRead™ register contains a programmable odometer. The odometers in the
previous examples are hard-wired to present either a four-digit or six-digit meter reading.
The odometer in the ProRead registers is also available with those options, but the meter can
be programmed to return up to the maximum number of digits that are hard-wired in the
odometers. Programming always begins at the leftmost odometer digit.
Example:
A four-digit hard-wired version can be programmed to read either:
l Four digits = 1234
l Three digits = 123
The four-digit hard-wired version cannot be programmed to return five digits or six digits. If
this accidentally occurs, the read would appear as an error.
Example: 1234-0
Likewise, a six-digit hard-wired version can be programmed to read:
1. Six digits= 123455
2. Five digits = 12345
3. Four digits = 1234
4. Three digits = 123
R900
®
Belt Clip Transceiver Users' Guide 19
Appendix A: N_SIGHT
®
Meter Reading and Override
