Meter Size A B C D E
3 inch 12.00 or 17.00 inches 9.65 inches 3.75 inches 0.71 inches 7.50 inches
4 inch 14.00 or 20.00 inches 10.94 inches 4.50 inches 0.71 inches 9.00 inches
6 inch 18.00 or 24.00 inches 12.73 inches 5.50 inches 0.71 inches 11.00 inches
Table 4 – Commercial and Industrial MACH 10
®
Meter Dimensions
Additional Specifications
The following specifications are for the 3-inch to 6-inch C&I meters.
Specification Description
Maximum operating pressure of
meter housing
175 psi (12 bar).
Register type Straight reading, permanently sealed electronic Liquid
Crystal Display (LCD); digits are 0.28" (7 mm) high.
Register display l Consumption (up to nine digits).
l Rate of flow.
l Alarms.
l Unit of measure factory programmed for gallons, cubic
feet, or cubic metres.
Battery 3.6 volt lithium thionyl-chloride; battery is encapsulated
within the replaceable UME.
Table 5 – Additional Specifications
Fluid Compatibility
The MACH 10 meter is designed and calibrated for potable, combination potable and fire
service, and reclaimed water across the defined temperature and velocity range.
Maincase
The C&I MACH 10 meter maincase is manufactured using lead free bronze and is a pressure
vessel that supports the UME. The UME is a replaceable assembly that contains all the
elements necessary for accurate measurement and registration of water, such as the
transducers, battery, electronics, and register.
Commercial and lndustrial MACH 10
®
Ultrasonic Meter Installation and Maintenance Guide 7
Chapter 2: Commercial and Industrial MACH 10
®
Specifications
