Commercial and lndustrial MACH 10
®
Ultrasonic Meter Installation and Maintenance Guide 13
Chapter 4: Installing MACH 10
®
Ultrasonic Meters
All MACH 10
®
ultrasonic meters are delivered activated and ready to be installed. When the
meter lid is opened, the meter shows the empty pipe icon and the latest volume on the LCD.
The empty pipe icon clears immediately after the meter is installed and the meter measuring
pipe is full.
Installation Instructions for MACH 10
®
Meters
This section defines the step-by step instructions for installing the MACH 10 meter.
Prior to Installation
This section defines the processes to perform before you install the meter.
Storage
After receipt, inspect the shipping containers for damage and inspect the contents of any
damaged cartons prior to storage. After completing the inspection, store the cartons in a
clean, dry environment. See Table 1 on page5.
Unpacking
After unpacking the MACH 10 meter, inspect it for damage. If the meter appears to be
damaged, notify your Neptune territory manager or distributor. If a meter requires
reshipment, use the original cardboard box and packing material.
Handling the Meter
Only use nylon straps with appropriate weight capacity to lift the meter from its installed lift
brackets (found on either side of the register).
DONOT:
- Lift the meter by the electronic housing unit.
- Carry the meter by its lid.
- Use bolt holes for grip when carrying the meter.
- Position the meter on its electronic housing unit.
