AP4.8 Connection and setting
AP4-12
AP4.8.3 Connection to multiple networks
1. Parts required
- Hub (When 100BASE-T PC is connected, the switching hub is required.)
- 10BASE-T or 100BASE-T straight LAN cable
- PC (with LAN port or LAN card)
- Router
2. Connection
Refer to the figure above.
1) IP address and Subnet mask
Default settings of IP address and subnet mask are as below. Change these values if
necessary.
- IP address : 172.31.16.1
- Subnet mask : 255.255.0.0
accordingly.
Procedure
2) Gateway
2. Select [Network Setup], followed by [Enter].
Ex)172.31x.x
Ex)172.30x.x
When a gateway (router) is connected to the network, gateway setting is required on
Refer page AP4-9 "3. Setting on Nera C ".
1. Press [F8][2] to open "Sy stem Setup" menu.
3. Select "Network", followed by [Enter].
3. Setting on Nera C
Nera C.
Nera C
Nera C
4. Select "Gat eway", followed by [Enter].
If the Nera C is connected to other network, the network address is changed
To Next Page
