Steps
1. Estimate cabinet weight on page 10
The cabinet reliably and safely transports up to 909.1 kg (2000 lb) of capacity. You need to know
the approximate weight of the cabinet so that you can safely move it.
2. Acclimate cabinet on page 11
Make sure that the cabinet and the trays are acclimated to the indoor environment before removing
the packing materials.
3. Remove packing materials on page 11
Remove the packing materials only after the cabinet has acclimated to the indoor temperature.
4. Checking shipping contents on page 12
Check the shipping contents to make sure that all equipment arrived at the site.
5. Remove heavy components from cabinet on page 12
Remove some of the heavier components that are located in the top of the cabinet to ensure
maximum stability.
Estimate cabinet weight
The cabinet reliably and safely transports up to 909.1 kg (2000 lb) of capacity. You need to know the
approximate weight of the cabinet so that you can safely move it.
Steps
1. Use the following table to calculate the approximate total weight of your cabinet.
The total weight of the cabinet depends on the number and type of trays that are installed in the
cabinet.
Component
Weight Notes
Cabinet 138.80 kg (306.0 lb) Empty with the rear door
installed
Power distribution units (PDUs
[pair])
19.96 kg (44.0 lb)
Mounting rails (pair) 1.59 kg (3.50 lb)
E2612 controller-drive tray 27 kg (59.52 lb) Maximum configuration
E2624 controller-drive tray 26.12 kg (57.32 lb) Maximum configuration
E2660 controller-drive tray 105.2 kg (232 lb) Maximum configuration
E2712 controller-drive tray 27.12 kg (59.8 lb) Maximum configuration
E2724 controller-drive tray 26 kg (57.32 lb) Maximum configuration
E2760 controller-drive tray 105.2 kg (232 lb) Maximum configuration
E5412 controller-drive tray 27.92 (61.52 lb) Maximum configuration
E5424 controller-drive tray 26.92 kg (59.32 lb) Maximum configuration
E5460 controller-drive tray 105.2 kg (232 lb) Maximum configuration
E5512 controller-drive tray 28.89 kg (63.7 lb) Maximum configuration
E5524 controller-drive tray 27.9 kg (61.52 lb) Maximum configuration
E5560 controller-drive tray 107.13 kg (236.2 lb) Maximum configuration
E5612 controller-drive tray 28.89 kg (63.7 lb) Maximum configuration
10 | Installing E-Series 3040 40U Cabinet
