Component kVA Watts BTU/Hr
E5412 controller-drive tray 0.558 552 1883
E5424 controller-drive tray and the EF540
flash array
0.607 601 2051
E5460 controller-drive tray 1.254 1242 4237
E5512 controller-drive tray 0.587 581 1982
E5524 controller-drive tray and the EF550
flash array
0.637 630 2150
E5560 controller-drive tray 1.285 1272 4342
E5612 controller-drive tray 0.625 619 2111
E5624 controller-drive tray and the EF560
flash array
0.675 668 2279
E5660 controller-drive tray 1.325 1312 4477
DE1600 drive tray 0.325 322 1099
DE5600 drive tray 0.375 371 1267
DE6600 drive tray 0.1.011 1001 3415
* The maximum ratings at 200 VAC. The BTU calculation is based on the maximum current rating
that the power distribution unit can provide.
Maximum number of trays
The maximum number of trays that you can install in a 3040 40U cabinet depends on the height of
each tray in rack units (U).
Tray heights in rack units (U)
Each rack unit is 1.75 inches (4.45 cm). For example, you can install up to ten 4U trays, up to twenty
2U trays, or a combination of 2U and 4U trays, up to 40U.
Tray
Rack units (U)
E2x12 or E2x24 controller-drive tray 2U
E2x60 controller-drive tray 4U
E5x12 or E5x24 controller-drive tray 2U
E5x60 controller-drive tray 4U
EF5x0 Flash Array 2U
DE1600 drive tray 2U
DE5600 drive tray 2U
DE6600 drive tray 4U
Overview and specifications | 7
