1.
Front adjustable rail
2. Rear adjustable rail
3. Adjustment plate and screws
4. Rail mounting M5×10mm screws
5. Clip nuts
6. Rear hold down bracket
7. Vertical support
Note: The clip nuts and the rear hold down bracket are not used when the rails are installed in a
3040 cabinet.
Install the cabinet |
19
