Smart Switch Software User Manual GS748T
4-4 Configuring the Switch
v1.0, October 2007
4. Click Apply.
The LAG Membership table displays the port members in each LAG. You can also specify port
members for LAGs. When specifying LAGs, the following policies apply:
• Each port can belong to only one LAG.
• Each LAG can have up to 8 ports.
• Ports in a LAG must have the same speed and be in the same VLAN group.
To configure port membership of a LAG:
1. Select Switching > LAG > LAG Membership. The LAG Membership screen will display.
2. From the LAG ID pull-down menu, select the LAG that you want to modify.
3. Click the Unit link next to the check box to display all available ports. (All ports are selected if
the Unit checkbox is selected. If not selected, no ports are selected.)
4. Select or clear the check box for the ports you want to include or remove.
5. Click Apply.
Figure 4-9
